Schwank Epic14 Series
Flexible climate separation
Le site Epic Series rideaux curtain is engineered avec une high-efficiency EC Motor, configurable contrôle offering, à gaz et flexibility dans handling une range de mounting heights (10′ to 14′) for industrial spaces. Available dans ambient à gaz et électrique heated models avec horizontal De Plus, vertical mounting capability.
Applications
- Entrepôts
- Distribution Centers
- Quai de chargement
- Fabrication
- Installations de transport
- Food storage
Vidéo
Points forts de la série Schwank Epic14
Réimaginez la séparation climatique flexible pour les espaces industriels.
La série Epic14 de Schwank se monte facilement sur les portes et peut être montée verticalement ou horizontalement. Associée à la dernière technologie de moteur EC et à des hauteurs de montage flexibles (10-14 pieds), la série Epic redéfinit les normes industrielles en matière de rideaux d'air.
Modèles disponibles
- Modèles : modèles à chauffage ambiant ou électrique.
- Tension : 208V1~, 208V3~, 480V3~, 600V3~
- Largeurs : 36", 42", 48", 60", 72", 84", 96", 108", 120".
- Moteur : Moteur à entraînement direct EC 1HP à haute efficacité énergétique.
- Montage : Hauteur de montage variable de 10 à 14 pieds. Recommandé 14 ft.
- Un design lisse et enveloppant dans une couleur grise pour s'intégrer harmonieusement dans l'espace.
- Garantie : 5 ans de garantie limitée (modèle ambiant), 1,5 an de garantie limitée (modèle chauffé électriquement)
Utilisez le curseur pour visualiser le rideau d'air Epic
avec et sans le bouclier avant.
Configurable Controls
· Control packages with a 4.3″ touchscreen.
· BACnet ready for seamless BMS integration.
· Stepless speed control and time delay features.
· Auto-regulate the heat and speed output based on a specified temperature difference.
Modern Design
Smooth front wrap design to blend seamlessly into the space. Plus, the front wrap is available in custom colors.
Ultimate Flexibility
A single unit offers multiple mounting heights, ranging from 10′-14′ ft. Plus, a single unit performs in multiple applications, from climate separation, and insect control.
Moteur EC économe en énergie
· Premium EC 1HP Direct Drive Motor.
· Are 2-3 times more efficient than standard PSC Motors.
· Flexible range in mounting heights from 10′-14′.
· Quick ramp-up time.
Caractéristiques
- Moteur EC économe en énergie
A premium EC 1HP Direct Drive Motor, which is 2-3 times more efficient than standard PSC Motors. - Maximum Accessibility
A unit where all electronic, motor, and blower changes can be made simply by removing the front panel, even when mounted. Plus, multiple options for wall and ceiling mounting brackets. - Ultimate Flexibility
A single unit offers multiple mounting heights, ranging from 10′-14′ ft. Plus, a single unit performs in multiple applications, from climate separation, and insect control.
- Configurable Controls
Model intelligence with configurable smart controls for adaptive time overrun for busy periods, stepless speed control, and auto speed control. All from a 4.3” touchscreen. - Modern Design
The smooth wrap design provides a modern feel, which blends seamlessly into the space. Plus, an optional front shield is available and in custom colors.
Accessoires en option
Included with your Schwank Epic14 Series air curtain: |
|
Basic (Default) Control Package
|
Intake Type
|
Options for your Schwank Epic14 Series air curtain: |
|
Advanced Control Package
|
Mounting hardware and kits
|
Interrupteur de porte
Disconnect switch
|
|
An optional front shield will add to the wrap design. Plus, it is available in pre-selected and custom colors*. |
||
Silver |
Orange |
White |
Black |
Grey |
Dark Blue |
